FINGER WHEEL “V” RAKES

30-80 HP (22-60 KW)

Rotomec “V” rakes are available in working widths ranging from 5,2 to 7,8 meters and working speeds of up to 22 km/h. The wide working widths along with the low cost of ownership make the “V” rakes suited for larger hay foraging operations. All “V” rakes are equipped with two hydraulic cylinders for easy transport and storage of the rake. Hydraulic ball valves allow for single sided operation and provide additional security while rake is in transport. The optional center kicker wheel turns the hay in the center to improve bailing results.

Standards

Reversible three point hitch for front or rear tractor mounting

Rakes can be used for raking, turning and spreading

Dual rear roller mounting position, inside or outside the cutting chamber

Two hydraulic cylinders with ball valves

Dual rear roller mounting position, inside or outside the cutting chamber

Narrow 2,4 meter transport width

Dual rear roller mounting position, inside or outside the cutting chamber

Springs adjust the pressure of the wheels to the ground

Technical features

HP 30-80
   cm 640
        Kg 585
    8
Ø cm 140
N° – Ø mm 40-7



HP 30-80
   cm 700
        Kg 661
    10
Ø cm 140
N° – Ø mm 40-7



HP 30-80
   cm 780
        Kg 736
    12
Ø cm 140
N° – Ø mm 40-7



Optional equipment

0099982

Ruota stellare centrale

HRC-001

Carrello di trasporto

Instruction manual

All models
